60 Tube mill/Pipe mill

ERW60 tube mill/pipe mill/welded pipe production/pipe making machine is used to produce steel pipes of 19mm-63mm in OD and 0.8mm-3.5mm in wall thickness, as well as corresponding square and rectangular pipe
Application
Advantage
Technical parameter
Video

Application

GI, construction, automotive, general mechanical tubing, oil and gas, conduit, agriculture, chemistry, conduit.

Advantage

  • High production efficiency, line speed can be up to 100m/min.
  • High automation
  • High strength, the machine works stably at a high speed, which improves product quality.
  • Low defectiveproduct rate
  • Siemens ,Yuskawa, Allen-Bradley motor as option

Technical parameter

Finished productRound PipeΦ19mm-φ63mm
Thickness: 0.8mm-3.5mm
Square & rectangle tube15mm×15mm-50mm×50mm

Thickness: 0.8mm-3.0mm

Length5m-12m
Length Tolerance±1.5mm
Production Speed60-100 m/min
Raw MaterialCoil material● HR/CR carbon steel or galvanized steel
● High-Strength Low -Alloy- Steel(HSLA)
● Advanced High-Strength Steels (AHSS)
Width60mm-200mm

Thickness: 0.8mm-3.5mm

Coil IDφ480-φ520mm
Coil ODφ1000~φ1500mm
Coil Weight2.5-3.0Tons

Video
